Measuring Devices and Calibration
Measuring Devices and Calibration

The laboratory facilities (more than 1200 sensors, calibration devices and loading systems) allow for static and dynamic testing on elements ranging in size from millimeters to hundreds of meters, as well as acoustic tests on components and assemblies. Vision based measuring devices allow the 3D motion estimation and the reconstruction of shape and strain conditions. Customized measurement systems can be developed according to the customers’ requests.
INSTRUMENTS & FACILITIES
- Electrodynamic shakers with a maximum force of 25 kN at 3.5 kHz.
- Several tens of sensors for mechanical and thermal measurements, especially for vibrations and NVH
- Different data acquisition systems for 3D Digital Image Correlation (DIC) for 3D strain field re-construction
- 3D vision-based scanners with customizable working volumes
- Infrared imaging for contactless thermal field measurements and non-destructive defect detection
- Laser-Doppler vibrometer for non-contact vibration measurement and modal analysis of mechanical systems
- Industrial cameras and lenses for vision-based measurements
- Hyperspectral Imaging System
- Thermo-vacuum chamber for the characterization of components between -180 and 200°C
ACCREDITED STAFF
NDT qualification in compliance with EN 473, ISO 9712 and SNT-TC-1A for testing with electrical resistance strain gauges (Level 1 and Level 2). NDT qualification in compliance with UNI EN ISO 9712:2012 (RINA RC/C.14 directive) – method “Acoustics and Vibration” (Level 3).
CERTIFICATIONS
Accredited laboratory for the calibration of acceleration transducer: Settore Accelerometria of Politecnico di Milano, Laboratorio Accreditato di Taratura LAT 104.
ACTIVITIES
Large/Small Structure Dynamic Testing and Monitoring
- Structural health monitoring of infrastructure (bridges, railways) and large civil structures (stadiums, skyscrapers), mechanical components, and cultural heritage
- Experimental and Operational Modal analysis
- Long-term continuous structural monitoring
- New sensor systems for civil and industrial engineering
- Human-structure interaction
Vibration Control and Monitoring with Smart Materials
- Vibration mitigation through smart approaches (e.g. piezoelectric shunt, shape memory alloys)
- Structural monitoring through smart materials
- Acoustic testing and analysis
- Noise source identification using microphone arrays
- Sound quality, synthesis and Psycho-acoustic analysis
- Vibro-acoustic correlations and path analyses (e.g. TPA, component-based TPA, substructuring)
Vision-Based Measuring Systems
- 3D measurements with drone-carried vision devices
- Contactless measurement of strain field for mechanical analysis
- Failure analysis of civil structures and concrete beams
- Remote monitoring of bridges vibration by means of vision-based devices
- Dynamic structural vibration measurements, including applications in harsh environments, e.g., helicopter blades tracking during operation
Artistic and Historical Landmarks Monitoring and Protection
- Historical and artistic structures monitoring
- Statue vibrations and seismic isolation
- Long-term continuous monitoring
Measurements for Space
- Development of FTIR spectrometers for remote sensing
- Development of opto-mechanical systems for space applications
- Characterization of mechanical systems under cryogenic conditions
- Qualification of components for space applications
